SimpleComTools, LLC
COM1000
 User Manual
SimpleComTools, LLC
RELAY
The on
board relay provides the ability to Open and Close a circuit, giving the device the ability to control external
devices, such as lighting systems, motors, alarms, etc.  The Relay tab is used to configure the state names as well
as sending SMS or SMTP or IM messages.
Parameter Name
Description
Name
Name used as Internet HOST and NETBIOS NAME for MS Windows Networks.
Accepts up to 50 alphanumeric characters.
Current State
Displays or changes current state of RELAY.
Command without '=n' will display state. Including '=n' will change the state.
Options:   0 = DE
ENERGIZE Relay (Turn it OFF)
1 = ENERGIZE Relay
(Turn it ON)
Relay ‘On’ Alias
Customizable Relay ON command. This is a free
text field to be used to create a term
to be interpreted as the *RO
AT Command. Example: entering the term ‘engine
would allow for the term 'engine
on' to be used as a command to ENERGIZE the relay.
(Accepts up to 20 characters).
Relay ‘Off’ Alias
Customizable Relay OFF command. This is a free
text field to be used to create a term
to be interpreted as the *ROFF AT Command. Example: entering the term ‘engine
off
would allow for the term 'engine
off' to be used as a command to DE
ENERGIZE the
relay. (Accepts up to 20 characters).
Relay ‘On’ Message
Customizable Relay ON (ENERGIZED) message. This is A free
text field used when
the Relay is in the active state. Text is used in all Serial, UDP, TCP, SMS, and SMTP
messages. For SMS and SMTP, this will be seen as the SUBJECT.
Example: :entering the  term
Engine1
On' would allow for the term 'Engine1
On' to
be the message sent when the relay is ENERGIZED. (Accepts up to 20 characters)
Relay ‘Off’ Message
Customizable Relay ON (ENERGIZED) message. This is A free
text field used when
the Relay is in the active state. Text is used in all Serial, UDP, TCP, SMS, and SMTP
messages. For SMS and SMTP, this will be seen as the SUBJECT.
Example: :entering the  term ‘Engine1
Off' would allow for the term 'Engine1
Off' to
be the message sent when the relay is ENERGIZED. (Accepts up to 20 characters)
Recipients
Desired Relay State message recipient(s) as detailed in the MESSAGING configuration
registers. (Comma separation for multiple, ie 1,3,8). Max number = 8.
Relay Auto
Off Time
Interval of timer the relay will stay energized after being turned on.
Options:   0 = not active (No auto
off feature)
65535 = number of seconds (65535 sec = 18.2 hours)
Scheduled Relay
Activation Timer
Sets the time interval for recurring relay triggering to take place within the same 24
hour
period. This requires that Relay Auto
Off Time also be set.
Options:
0 = no timer active (DEFAULT)
1440 = number of minutes between relay triggers
Scheduled Relay
Activation Time of Day
Sets the TIME OF DAY for regularly scheduled relay triggering. Set the time valu
using the format HH:MM. Must enter value in Military time.
Note: Requires that the value DAY OF WEEK or DAY OF MONTH be set as well.
Scheduled Relay
Activation Day of Week
Sets the DAY OF WEEK for regularly scheduled relay triggering. Only set this value if
you do NOT want the relay to be triggered every day.
Options:
0 = Every Day  (DEFAULT)
7 = Day of the Week starting with Sunday. (Sun=1, Mon=2, Tue=3, etc)
Scheduled Relay
Activation Day of Month
Sets the DAY OF MONTH for regularly scheduled relay triggering. Set this value if you
do NOT want the relay to be triggered every day.
Options:
0 = Every Day  (DEFAULT)
31 = Day of the Month. (1=1
day, 2=2
day, etc)
