SimpleComTools, LLC
COM1000
 User Manual
SimpleComTools, LLC
Trigger 1
Sets the trigger that will initiate the Application #1 event.
Enter the value representing how you want the application to start.
Options:
0 = No Action
1 = Timer
     (Send inbound data every 'n' minutes (*TTIMER1)
2 = Intercharacter Timer (ICT)
     (Send inbound data after pause between characters (*TICT)
3 = Serial Stream Value
     (Send data based on specific serial stream characters (*TSTREAM1)
4 = Buffer Limit
     (Send data after reaching a specific data limit (*TBUFFE
Trigger 2
Sets the trigger that will initiate the Application #1 event.
Enter the value representing how you want the application to start.
Options:
Same as Trigger 1
Trigger 3
Sets the trigger that will initiate the Application #1 event.
Enter the value representing how you want the application to start.
Options:
Same as Trigger 1
Elapsed Timer 1
485 Port Application #1 Timer Trigger. Value 'n' is in minutes. This is the period of
time to wait before executing *TAPP1. This value requires that RS
485 PORT APP #1
TRIGGER be set to 1 (Timer).
Elapsed Timer 2
485 Port Application #2 Timer Trigger. Value 'n' is in minutes. This is the period of
time to wait before executing *TAPP1. This value requires that RS
485 PORT APP #2
TRIGGER be set to 1 (Timer).
Elapsed Timer 3
485 Port Application #3 Timer Trigger. Value 'n' is in minutes. This is the period of
time to wait before executing *TAPP1. This value requires that RS
485 PORT APP #3
TRIGGER be set to 1 (Timer).
Data Stream 1
Serial Data Stream used to trigger events (Up to 20 characters). This is the exact text
being filtered before executing any of the *TAPP selections. This value requires that
485 PORT APP #1 TRIGGER be set to 3 (Stream).
Data Stream 2
Serial Data Stream used to trigger events (Up to 20 characters). This is the exact text
being filtered before executing any of the *TAPP selections. This value requires that
485 PORT APP #2 TRIGGER be set to 3 (Stream).
Data Stream 3
Serial Data Stream used to trigger events (Up to 20 characters). This is the exact text
being filtered before executing any of the *TAPP selections. This value requires that
485 PORT APP #3 TRIGGER be set to 3 (Stream).
Inter Character Timer
485 Port Inter
Character Timer. (n = 1
5000 milliseconds). This is the length of the
pause between characters in the serial data stream before executing any of the *TAPP
selections. This value requires that RS
485 PORT APP #1, 2 or 3 TRIGGER be set to 2
(Inter
character Timer).
